TRA71076-3 Traxxas E-Revo VXL: 1/16-Scale 4WD Racing Monster Truck With TQi Traxxas Link Enabled 2.4Ghz Radio System & Traxxas Stability Management (TSM)

Off-Road Excitement. Anytime. Anywhere

The E-Revo VXL is built on the race-winning, track-proven innovation of the Revo and E-Revo models. The Revo’s rocker-actuated suspension has been expertly adapted to 1/16 scale with all its functionality and performance intact, right down to the oil-filled, threaded-body GTR shocks. This superior technology provides capability, performance, and tuning functions at the absolute pinnacle of truck design. Intricately molded as a single piece, the monocoque chassis balances strength and weight to far surpass the standards of the “mini” category. In 1/16 scale, it is an even more impressive achievement of packaging and performance optimization that could only come from Traxxas, The Fastest Name In Radio Control^®.



Class-Leading Speed

Some mini-models are “fast for a mini.” That’s not good enough for Traxxas. The 1/16 E-Revo VXL is just plain fast. At 30+mph with the included 6-cell NiMH battery, E-Revo VXL is nearly twice as fast as most mini models, and faster than most electric RTR trucks of any scale. Install a second 6-cell battery to unleash the Velineon Brushless Power System’s full fury, and E-Revo VXL jumps to over 50mph. No other RTR truck, regardless of scale, makes it so easy and affordable to experience this level of high speed and wheelie-popping power.



Velineon Brushless Power

Built specifically for Traxxas 1/16 scale models, the VXL-3m speed control and Velineon^® 380 motor represent the latest in brushless technology. Fully LiPo compatible with low-voltage detection for 2S and 3S packs and rated for 6-12 NiMH cells, this potent, powerful combo gives E-Revo VXL precise throttle control and blistering top speed. The Velineon 380 is built to the same no-compromise specs as the Velineon 3500 found in Traxxas’ 70+mph 1/10 scale VXL models. High-speed ball bearings. Sintered rotor. Neodymium magnets. Gold plated 3.5 mm connectors. It all adds up to 50,000 rpm of pure power and speed!





• ProGraphix^® Painted Body
  • 1/16 Scale pre-painted body with applied decals
  • High-downforce composite wing
• Waterproof VXL-3m™ Electronic Speed Control
  • Innovative waterproof design
  • Three drive profiles
    • Sport Mode – forward / brake / reverse
    • Race Mode – forward / brake
    • Training Mode™ – 50% forward / brake / 50% reverse (patented)
  • Traxxas EZ-Set^® one-button setup
  • High-capacity heat sink
  • NiMH battery packs: 6-12 cells (7.2 to 14.4 volts)
  • LiPo battery packs: 2-3 cells (7.4 to 11.1 volts)
• Velineon^® 380 Brushless Motor
  • Powerful 8-turn, 4000kV design
  • Optimized for smooth sensorless power
  • Ultra high-temperature sintered Neodymium motor magnets
  • Gold-plated 3.5mm bullet connectors
• Traxxas Stability Management^® (TSM)
  • Improves straight line acceleration and braking on low-traction surfaces
  • Maintains steering composure to allow throttle-on powerslides
  • Never dulls throttle or slows the vehicle
  • Adjusts from off to 100% assistance from the transmitter

• TQi™ 2.4GHz High Output Radio System
  • TQi 2-channel transmitter
  • 5-channel micro receiver (#6533) with fail-safe security and integrated telemetry ports
  • Compatible with optional TQi Traxxas Link Wireless Module (#6511) to access full Traxxas Link app functionality (sold separately)
  • Automatically stores and loads settings for up to 30 Traxxas Link-enabled models
  • Programmable multi-function knob
  • Adjustable steering and throttle percentage (dual rates)
  • Adjustable steering and throttle sensitivity (exponential)
  • Adjustable steering and throttle end points
  • Patented waterproof receiver box
• Includes Battery and Charger
  • 2-amp 12V DC Peak Detecting Fast Charger
  • 1200mAh Traxxas 6-cell 7.2V NiMH battery with iD™
• Fiber-Composite Monocoque Chassis
  • Low-CG design for improved handling
  • Tough skid plates for driveline protection
  • All electronics securely fastened to chassis
• Dual Integrated Battery Compartments
  • Quick-release battery doors for fast pack changes
  • Intake and exhaust cooling vents keep battery temperatures down
  • Accepts 1/16 scale NiMH and LiPo batteries

• Transmission and Driveline
  • Full-time shaft-driven 4WD
  • Sealed heavy-duty transmission
  • Adjustable slipper clutch
  • Sealed, silicone-filled differentials with steel gears
  • Heavy-duty telescoping U-joint driveshafts
• Steering
  • Digital waterproof Traxxas #2080 steering servo
  • Servo horn with integrated servo saver
• Suspension
  • Twin-arm pivot ball suspension
  • Progressive rocker-arm damping for extreme travel
  • Captured rod ends won’t pop off
• Springs and Shocks
  • Inboard fully adjustable oil-filled GTR™ shocks
  • Adjustable pre-load collars
  • Red powder-coated springs
• Wheels and Tires
  • Pre-glued Talon™ tires with high-performance foam inserts
  • 53mm Gemini 5-spoke chrome wheels
• Rubber-Sealed Ball Bearings
• Precision Hex Hardware
• Backed by Unparalleled Traxxas Support and Parts Availability
