Features
- Ready-to-run
- Spektrumâ„¢ SLT3â„¢ 2.4GHz 3-Channel Radio
- Spektrumâ„¢ SR315 Dual Protocol 3-Channel Receiver
- Spektrumâ„¢ S652 Digital Servo
- Spektrumâ„¢ Firmaâ„¢ 150A Smart ESC
- Spektrumâ„¢ Firmaâ„¢ 4074 2050Kv Brushless Motor
- Stronger chassis design
- EXB compatible front brace
- Heavy-duty arms front and rear
- Updated Rear shock tower geometry
- Large volume waterproof* receiver box
- Anodized aluminum chassis
- Strong composite chassis side pods
- Center body support and brace for maximum durability
- Internal body protection roll bar
- High downforce wing
- Wheelie bar
- Oil-filled adjustable shocks
- Black-anodized aluminum front and rear shock towers
- Durable steel driveshafts throughout
- Heavy-duty drivetrain
- All-metal diff outdrives and gearbox internals
- Never-loose red aluminum servo saver
- Never-pop ball ends
- 5-Bolt center diff removal
- Easy-access sliding motor mount for quick motor removal
- Hub nut O-rings
- Super-durable wheel hubs for increased strength
- Tough stunt truck wheels
- Multi-terrain dBoots® BACKFLIP™ tires
- “Real Steel” effect body for enhanced realism
- IC5® connectors (EC5™ compatible)
- 2-year limited warranty (see manual for details)
*For details on waterproof standards, please refer to the product instruction manual
Â
Overview
From its heavy-duty front bumper through the short wheelbase chassis to the wheelie bar in back, the NOTORIOUS™ 6S BLX 4WD is engineered to make you a stunt superstar. Its stiff roll cage and underbody will take all kinds of punishment and come back for more. The NOTORIOUS™ 6S BLX 4WD can do it all: long, tall wheelies…tight, fast donuts…standing and aerial backflips…high leaps into the air…and more.
For the power to perform that kind of stunt action, ARRMA® now equips the NOTORIOUSâ„¢ 6S BLX 4WD with a potent, 6S-capable brushless system featuring the Spektrumâ„¢ Firmaâ„¢ 150A Smart ESC and Firmaâ„¢ 2050Kv brushless motor. The combination lets you cut loose with incredible torque, acceleration and speed, while the heavy-duty aluminum and steel chassis and transmission components take it all in its stride. For improved steering, ARRMA® also includes a new, steel gear Spektrumâ„¢ S652 Digital Servo — which is 32% stronger and 5% faster than the previous version’s ADS-15M servo. Thanks to waterproof electronics, bashing is a “go” even through mud and snow. Just add your favorite 4S or 6S LiPo battery.
The ready-to-run Stunt Truck now also includes a 3-channel Spektrumâ„¢ SLT3â„¢ radio and Spektrumâ„¢ SR315 dual protocol receiver. Perfect for long hours of fatigue-free bashing, the transmitter’s ergonomic design features a foam steering wheel for precise fingertip control and an improved hand grip and trigger feel. If you’re a new driver, you’ll be able to set throttle limits at 50% or 75% until you’re ready to use the full speed potential. The SLT3â„¢ is compatible with Tactic® SLTâ„¢ receivers to run other RTR vehicles you may own, and includes a third channel to control optional features such as lights and winches on models that have them.
Because the SR315 receiver can use SLTâ„¢ and DSMR® protocols, you can easily upgrade to a Spektrumâ„¢ DSMR® transmitter later — then, download the free Spektrumâ„¢ Dashboardâ„¢ app for your mobile device and take full advantage of the Smart telemetry capabilities already present in the Firmaâ„¢ electronics. You’ll be able to receive real-time updates of ESC temperature, receiver (BEC) voltage, drive pack voltage and motor RPM.
With adjustable 16mm oil-filled shocks on aluminum towers soaking up bumps, the NOTORIOUSâ„¢ 6S BLX 4WD Stunt Truck blasts over dirt, asphalt, and grass — over all terrain, in all conditions. Its tough stunt truck wheels come outfitted with multi-terrain dBoots® BACKFLIPâ„¢ tires that provide all the traction you’ll need to flip, grip, wheelie and spin. A high downforce wing helps keep the vehicle grounded. Everything about the NOTORIOUSâ„¢ 6S BLX 4WD contributes to confident control and responsive handling at thrilling high speeds.
For the toughness needed to support extreme stunts, ARRMA® uses a strengthened anodized aluminum chassis as the foundation. A center body support and aluminum center brace plus composite chassis side pods add more durability. All-metal diff outdrives and gearbox internals plus durable steel driveshafts provide a reliable, heavy-duty drivetrain that holds up to extreme stunts and high-speed bashing. A “never loose” aluminum steering servo saver and “never pop” ball ends supply more precision, reliability and confidence.
ARRMA® keeps your maintenance downtime to the minimum by giving the NOTORIOUS™ 6S BLX 4WD an efficient, driver-friendly design. A sliding mount allows quick, hassle-free motor access. The center diff is easy to reach and can be removed by taking out just five bolts.
Â
STANDING BACKFLIP?
No Problem. The NOTORIOUS 6S flips for fun.
Â
CATCH THE DRIFT
Can you control this much power long enough?
Â
UPDATED CHASSIS DESIGN
Wider rear section and 3D form introduced in key areas to greatly improve strength.
Â
UPDATED REAR SUSPENSION GEOMETRY
- Updated rear shock tower geometry works in conjunction with updated rear suspension arm geometry to provide a plusher rear end
- More compact rear shock tower, being less exposed, is better protected from being bent during upside-down impacts
Â
FRONT PIVOT BALL SUSPENSION
For precise handling at top speeds
Â
QUICK MAINTENANCE
5 bolt center diff removal for easy access
Â
SPEKTRUM® SMART TECHNOLOGY INCLUDED
FIRMAâ„¢ 150A SMART Brushless ESC and FIRMAâ„¢ 4074 2050Kv Brushless Motor
Â
GO LARGE
Large volume waterproof receiver box
Â
RUBBER SHIELDED BEARINGS
Longer life, less maintenance
Â
OPTIONAL SPEED PINION INCLUDED
Red anodized motor mount and Mod 1 spur and pinion gears to handle optimum performance.
Â
FIRMAâ„¢ 150A SMART Brushless ESC
- Waterproof* and dustproof design
- 150A, 6S LiPo ready (3S, 4S & 6S LiPo compatible)
- Spektrum® SMART Technology
- Fitted with reliable IC5® connectors (EC5™ compatible)
- Integrated fan for reduced heat during extreme running
- High quality 10awg wires
- Low voltage cut off and thermal overload protection
- User programmable punch, brake, BEC, reverse speed and motor timing settings
*For details on waterproof standards, please refer to the product instruction manual
Â
FIRMAâ„¢ 4074 2050Kv Brushless Motor
- 2050Kv 4074 size 6S brushless motor
- Beautifully etched aluminum can
- 4-pole construction for smooth and consistent power
- 4mm gold bullet connectors for reliable and efficient connection
- Black anodized aluminum motor can for increased heat dissipation
- Super strong 5mm shaft
- Groove at the end of the motor shaft allows the installation of a pinion retaining E-Clip
Â
SPEKTRUM® SLT3® RADIO
- Superb SLT response rate
- 50% and 75% throttle limited switch – great for beginners
- Steering & throttle rate & trim adjustments with throttle and steering reversing
- Foam steering wheel grip
- Compatible with Tactic Receivers
Â
SPEKTRUM® SR315 RECEIVER
- Dual Protocol – Compatible with SLT and DSMR® 2.4GHz protocol transmitters
- Fast reponse rate and outstanding range
- No tool binding and protocol switching
- SMART telemetry compatible (in DMSR mode and with SPEKTRUM dashboard app)
- 3-Channels
Â
SPEKTRUM® SPMS652 DIGITAL SERVO
- All Steel Gears
- Waterproof*
- 19.08kg-cm/265oz-in Torque @7.4V
- 32% More Torque & 5% Faster than ADS-15M Servo
*For details on waterproof standards, please refer to the product instruction manual
Specifications
Approximate Assembly Time
- No assembly required
- Ball Bearings
- Full set
- Battery
- Sold Separately
- Body
- Painted, trimmed and decaled
- Brakes
- User programmable
- Charger
- Sold Separately
- Chassis
- 0.12″ (3mm) 6061-T6 aluminum
- Completion Level
- Ready-To-Run
- Differential
- Front center and rear geared differentials
- Drive Type
- Forward/Brake/Reverse
- Drivetrain
- 4WD
- Final Drive Ratio
- 17.92
- Front Shock Spring Rate
- 5.0lbs/in (0.87n/mm)
- Front Track
- 18.15″ (461mm)
- Gear Pitch
- 1.0MOD
- Internal Gear Ratio
- 4.3
- Motor Size
- 4074
- Motor Type
- Brushless – Sensorless
- Pinion
- 12T
- Power Type
- Electric
- Product Height
- 9.06″ (230 mm)
- Product Length
- 21.26″ (540 mm)
- Product Weight
- 11.37lbs (5.17kg)
- Product Width
- 18.15″ (461 mm)
- Radio
- Included
- Rear Shock Spring Rate
- 6.2lbs/in (1.09n/mm)
- Rear Track
- 18.15″ (461mm)
- Receiver
- Included
- Scale
- 1/8
- Search Keywords
- ARRMA Firma RTR
- Servos
- Included
- Shock Type
- Aluminum body oil-filled adjustable
- Speed Control
- Included
- Spur Gear
- 50T
- Suspension
- Independent
- Tire Tread
- dBoots BACKFLIP
- Tire Type
- Multi-terrrain
- Vehicle Type
- Rock Racer
- Water-Resistant
- Yes
- Wheel Hex Size
- 17mm
- Wheel Type
- MT, 3.8″ (97mm) diameter
- Wheel Width
- 3.0″ (77mm)
- Wheelbase
- 12.91″ (328mm)
